◆FEATURES
●Fast response accuracy to ±0.1℃.
●Interchangeable or Point Matched tolerances
●The UMT Series Continuous Cardiac Output Monitoring. racy to ±0.1 ℃
●Thermal dilution catheters, esophageal catheters.
●Foley catheters electric.
●Internal Body Temperature monitoring.
●Other Disposable Temperature monitoring.
◆SPECIFICATIONS
●
Temperature rating : -50℃ to 150℃
●
B value : 3811K ~ 3942K
●
Determined by rated zero-power : Resistance at 25℃and 85℃
●
Resistance value at 25℃ :
10 K ohms
30 K ohms
47 K ohms
50 K ohms
Dissipation constant 0.3mW/℃ in still air
2.5mW/℃ in stirred oil
Thermal time constant Typically 0.25 seconds in air.
Tolerance ±0.5% ±1% ±3% ±5%
◆Order Map
| Series Code |
Res. value |
Res. Tolerance |
Lead Gauge |
Lengths |
B value |
| UMT |
103 |
D : ±0.5 % |
AWG Number |
Exp :400: 400 mm |
25℃/85℃ |
| Temperature Sensor |
at 2 5℃ 10 x 103 Ω |
F : ± 1% |
|
|
|
| |
|
H : ± 3% |
|
|
|
| |
|
J : ± 5% |
|
|
|
