◆FEATURES


●Fast response.
●The UTS Thermistor is smaller than the Chip thermistor.
●Its rapid response time and high reliability make it.
●Suitable for use in medical equipment and thermometers.
●Excellent thermal cycle endurance.
●Small size and high reliability.


◆SPECIFICATIONS


●Temperature rating  : -40℃ to 150℃
●B value : 3320K ~ 4200K
●Determined by rated zero-power : Resistance at 25℃and 85℃

●Resistance value at 25℃  :

5 K ohms
10 K ohms
47 K ohms
50 K ohms
100 K ohms


Dissipation constant          0.7mW/℃
Thermal time constant      Typically 3.2 seconds in air.
Maximum power Rating   3.5 mW at 25℃
Tolerance                            ±0.5%    ±1%   ±3%   ±5%


◆Order Map


Series Code	Res. value	Res. Tolerance	Lengths	B value
UTS	103	D : ±0.5 %	Exp:150 : 150 mm	25℃/85℃
Temperature Sensor	at 2 5℃  10 x 103 Ω	F :  ±  1%
		H : ±  3%
		J  :  ±  5%
